1× magnification | 21 mm objective | High mount, 40.4 mm center height
Circle-dot reticle with a 3 MOA center dot. Side-load CR2032 battery, motion activation and 8 daytime + 2 NV settings. Contact HERTDOT for bulk order inquiries.
Add a compact enclosed optic to your rifle optics assortment. The HERTDOT RALD21NCP combines 1× magnification, a 21 mm objective lens and a high mount with a 40.4 mm center height. Top-mounted controls and a side-load CR2032 battery keep the layout easy to review when choosing a configuration for your catalog. Share your target quantity and destination market, and we will help you prepare a product quotation.
The RALD21NCP places its plus/minus buttons on top of the enclosed housing. Its 21 mm objective lens and high-mount configuration give your purchasing team a compact option to compare across the range.
The CR2032 battery loads from the side. Specified battery life is 100,000+ hours at a low illumination level, with a low-power alarm to indicate when attention is needed. Keep the brightness condition alongside the battery-life figure when comparing specifications.
The optic powers off automatically after 2 minutes without motion and powers on when motion is detected. This gives your catalog a clear, easy-to-explain power-management feature.
With 8 daytime settings and 2 night-vision settings, buyers can choose an illumination level for different conditions. The circle-dot reticle combines a surrounding circle with a 3 MOA center dot. Tell us which reticle and color configuration you need for your order.
A CNC-machined 6061 aluminum housing, multi-coated glass and 1× magnification define the construction and optical format. The supplied ratings are IPX7 waterproofing at 1 meter for 30 minutes and 1500 G shock resistance. Review these values alongside the size and weight when selecting products for your assortment.
| Model | RALD21NCP |
|---|---|
| Magnification | 1× |
| Objective lens diameter | 21 mm |
| Size (L × W × H) | 47 × 36 × 67.8 mm (with high mount) |
| Weight | 116 g |
| Illumination source | High-efficiency LED |
| Solar panel | No |
| Lens material / treatment | Multi-coated glass |
| Reticle Options |  |
| Motion activation | Automatic power-off after 2 minutes without motion; powers on when motion is detected |
| Eye relief | Unlimited |
| Click value | 1 MOA |
| Parallax | ≤2 MOA |
| Parallax setting | 100 yards |
| Center height | 40.4 mm |
| Total elevation adjustment range | 90 MOA (±45 MOA) |
| Total windage adjustment range | 90 MOA (±45 MOA) |
| Battery | CR2032 — side load |
| Battery life | 100,000+ hours at low illumination level |
| Illumination settings | 8 daytime + 2 night-vision settings |
| Low-power alarm | Yes |
| Housing material | CNC-machined 6061 aluminum |
| Waterproof rating | IPX7 (1 meter for 30 minutes) |
| Shock resistance | 1500 G |
| Operating temperature | −20°C to +40°C (−4°F to +104°F) |
| Storage temperature | −30°C to +50°C (−22°F to +122°F) |
| Mount type | High mount |
Bring RALD21NCP into your selection with a 21 mm objective lens, motion activation and side-load CR2032 battery. Share your required reticle, mounting setup, quantity and destination market so we can address the details that matter to your purchasing team.
Planning a sample evaluation or a branded product offering? Include your sample, logo, packaging and documentation requirements in your inquiry. We will confirm available options, minimum order quantity, lead time and commercial terms for your request.
| Mount type | High mount |
|---|---|
| Center height | 40.4 mm |
| Rail / mounting interface | |
| Included accessories | |
| Product documentation |
| Minimum order quantity | |
|---|---|
| Sample policy | |
| Production lead time | |
| Branding / packaging options | |
| Warranty |
Send us your quantity, reticle preference, mounting requirements and destination market. HERTDOT will help you confirm the product configuration and prepare a quotation for your next order.
